JNF FREE SWING PIVOT SET HEAVY DUTY FOR WOODEN DOORS ( 500KG) – IN.05.501

IN.05.501 – JNF FREE SWING PIVOT SET HEAVY DUTY FOR WOODEN DOORS ( 500KG)

– Mechanical pivot system
– 501 FREE is a high-capacity mechanical pivot system designed for doors up to 500kg. The pivot mechanism is fully embedded in the door leaf, maintaining clean visual lines with no exposed external elements.
– Heavy-duty pivot system for doors weighing up to 500 kg.

– Designed to deliver maximum efficiency, the pivot door system combines high load capacity with exceptional performance. Its advanced engineering ensures smooth and seamless opening and closing, providing a refined and quiet user experience.
– With precise adjustment features, it allows for fine-tuning during installation to ensure perfect alignment and highly accurate results. Ideal for projects demanding quality, durability, and sophisticated aesthetics.

PIVOT FEATURES
– Free swing pivot without opening limit
– Door weight up to 500kgs
– Adjustment of position on the upper swing and base
– Upper pivot with needle bearing
– Installation of the upper pivot from the top of the door
– No floor cutting or masonry work required for installation
– Various bases available for different applications
– Applicable to single or double-action doors
– Minimum distance from the axis to the top of the door: 150mm
– Minimum door thickness: 45mm
– Door width up to 3000mm
– Power guide function, to electrify the door
